Gabion
Welded Gabion
Welded gabion baskets are constructed from steel wire welded into rigid mesh panels, forming box-shaped structures that are filled with stones. Unlike traditional hexagonal gabions, welded gabions offer a cleaner, more uniform appearance with precise dimensions, making them ideal for architectural applications and high-load retaining structures. The rigid panel construction provides superior strength and dimensional accuracy.
Inquiry NowProduct Features
Rigid welded mesh panels provide precise, uniform dimensions
Higher load-bearing capacity than hexagonal gabion baskets
Clean, modern appearance suitable for architectural applications
Faster assembly with pre-fabricated panel system
Excellent structural stability for tall retaining walls
Available in custom sizes and panel configurations
Smooth surface finish ideal for urban and decorative use
Compatible with various stone fill materials
Applications
Highway and railway retaining walls
Urban landscaping and decorative walls
Bridge abutment and wing wall protection
Commercial building facade cladding
Noise barrier structures
Flood control and river training works
Slope stabilization
Architectural feature walls
Technical Specifications
| Wire Diameter | 3.0 mm – 6.0 mm |
| Mesh Opening | 50×50 mm, 75×75 mm, 100×100 mm |
| Panel Size | Custom sizes available |
| Material | Low carbon steel wire |
| Surface Treatment | Hot-dip galvanized, Galfan coated, PVC coated |
| Tensile Strength | ≥ 400 N/mm² |
| Weld Shear Strength | ≥ 2.5 kN |
| Zinc Coating | ≥ 200 g/m² (hot-dip galvanized) |
| Standard | EN 10223-3, ASTM A975 |
